| Type Number | Main Difference |
| RW168AA | RS232(Output 4 bytes UID) |
| RW168AC | USB Virtual COM(Output 4 bytes UID) |
| RW168AA-D | RS232(Output 5 bytes UID) |
| RW168AC-D | USB Virtual COM(Output 5 bytes UID) |
| RW168JA | USB Keyboard Emulation(Output decimal numbers) |
| RW168JC | USB Keyboard Emulation(Output Hex numbers) |
| RW168J1-13 | USB Keyboard Emulation(Output Hex numbers) |
| RW168J1-11 | USB Keyboard Emulation(Output decimal numbers) |
| RW168AHB | USB(HID Passive Read) |
>>Features
- Frequency:125KHz
- Embedded with 125KHz RF base station
- Search card automatically,when having tag in the antenna field,the Tag UID No will be send out through RS232/USB interface.
- Special remarks for Keyboard Emulation:The RW163Jx reader has the function of USB Human Interface Device keyboard emulation.The reader reads the Tag UID,and then pastes it as a string at the cursor position into the host applications,like word,excel,notepad,brower,etc.
- Dimension:117mm*100mm*30mm
- Support EM/TK4001 or EM/TK4100 and compatible cards
- Embeded with watchdog
- Interface:USB/RS232
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Electrical Characteristics
- Frequency: 125KHz
- Operation distance :40~60mm
- Interface: USB/RS232
- PowerSupply:DC5V
- Operation current:5V/50mA
- Temperature range:-10℃～+70℃
- Dimension:117mm*100mm*30mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| RW168AA | RS232(Output 4 bytes UID) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168AC | USB Virtual COM(Output 4 bytes UID) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168AA-D | RS232(Output 5 bytes UID) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168AC-D | USB Virtual COM(Output 5 bytes UID) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168JA | USB Keyboard Emulation(Output decimal numbers) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168JC | USB Keyboard Emulation(Output Hex numbers) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168J1-13 | USB Keyboard Emulation(Output Hex numbers) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168J1-11 | USB Keyboard Emulation(Output decimal numbers) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
| RW168AHB | USB(HID Passive Read) | EM4001,EM4100,TK4001,TK4100 and compatible cards |
