| Type Number | Main Difference |
| M120Bx | IIC |
| M120Dx | UART(9bits) |
| M120DPCSx | UART(8bits) |
>>Features
- M120V71 IIC will be phase out,and will be repalced by M120V71N or other serials
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standard of ISO14443 TYPE A/Mifare
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Integrated with antenna
- Dimension include antenna:63X35mm
- Communication interface:IIC or UART
- Embeded with watchdog
- Source code samples for C51
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Optional antennas(None)
| Type Number | Dimension | Operation Distance |
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:40~60mm(Testing base on standard S50)
- Power Supply:DC3.3V/DC5V
- Current:Standard modules:3.3V/35mA(High Power Modules:3.3V/90mA)
- Temperature range: -10℃～+70℃
- Demision:63X35mm
- Pin to pin distance:2.54mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| M120BV3 | DC3.3V, Low Power, IIC | Mifare S50,S70,FM11RF08 and compatible cards |
| M120BV5 | DC5V, Low Power, IIC | Mifare S50,S70,FM11RF08 and compatible cards |
| M120DV3 | DC3.3V, Low Power, UART(9bits) | Mifare S50,S70,FM11RF08 and compatible cards |
| M120DV5 | DC5V, Low Power, UART(9bits) | Mifare S50,S70,FM11RF08 and compatible cards |
| M120DPCSV3 | DC3.3V, Low Power, UART(8bits) | Mifare S50,S70,FM11RF08,FM1208,FM1204,Desfire and compatible cards(M120DPCV3's update product) |
| M120DPCSV3B | DC3.3V, High Power, UART(8bits) | Mifare S50,S70,FM11RF08,FM1208,FM1204,Desfire and compatible cards(M120DPCV3B's update product) |
| M120DPCSV5 | DC5V, Low Power, UART(8bits) | Mifare S50,S70,FM11RF08,FM1208,FM1204,Desfire and compatible cards(M120DPCV5's update product) |
| M120DPCSV5B | DC5V, High Power, UART(8bits) | Mifare S50,S70,FM11RF08,FM1208,FM1204,Desfire and compatible cards(M120DPCV5B's update product) |
