| Type Number | Main Difference |
| M102EETV3B | DC3.3V, ISO14443A/B/ISO15693/ISO7816 |
| M102EETV5B | DC5V, ISO14443A/B/ISO15693/ISO7816 |
| M102EHTV3B | DC3.3V, ISO15693 |
| M102EHTV5B | DC5V, ISO15693 |
>>Features
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standards of ISO14443 TYPE A/TYPE B/ISO15693/Filica/Mifare/ISO7816
- The module has the function of detecting whether the M1 card is a cloned card (Only for UID,not for the block data)
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Dimension:32.5X17.5mm(DIP26)
- Communication interface: UART
- Embeded with watchdog
- Souce code samples for C51,Android,Windows,Linux
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Optional antennas
| Type Number | Dimension | Operation Distance |
| T182 | 32.5X17.5mm | 20~30mm |
| T186 | Outside diameter:31mm | 20~30mm |
| T101 | 65X59mm | 50~70mm |
| T102 | 41X42mm | 30~40mm |
| T105 | 128X142mm | 80~100mm |
| T107 | 192X155mm | 90~120mm |
| T120 | 63X35mm | 30~40mm |
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:20~100mm(Testing base on standard S50)
- Power Supply:DC3.3V/DC5V
- Current:Standard modules:5V/100mA
- Temperature range:-10℃～+70℃
- Demision:32.5X17.5mm
- Pin to pin distance:2.54mm(DIP26)
>>Main Difference
| Type Number | Main Difference | Support Tags |
| M102EETV3B | UART, DC3.3V, High Power, ISO14443A/B/ISO15693/ISO7816 | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M102EETV5B | UART, DC5V, High Power, ISO14443A/B/ISO15693/ISO7816 | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M102EHTV3B | UART, DC3.3V, High Power, ISO15693 | ISO15693 NXP I code 2, TI HF tagit |
| M102EHTV5B | UART, DC5V, High Power, ISO15693 | ISO15693 NXP I code 2, TI HF tagit |
