| Type Number | Main Difference |
| CustomerNo-X | Most of the multi-antenna modules are customized according to the customer requirement, so the model is defined as CustomerNo-X |
>>Features
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standards of ISO14443 TYPE A/Mifare
- Up to 6 antennas can be supported at the same time, and user cost can be greatly reduced under certain circumstances.
- Integrated with antenna
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Dimension:According to the customer requirement
- Communication interface: UART/RS232/RS485
- Embeded with watchdog
- Souce code samples for Android,Java,Javascript,VC,VB,C++ Builder,DELPHI,Power Builder,C#,CVI,etc
- PC DEMO for users
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:20~40mm(According to the tag)
- Communication interface: UART/RS232/RS485
- Power Supply:DC5V
- Current:Standard modules:5V/100mA
- Temperature range:-10℃～+70℃
- Demision: According to the customer requirement
>>Main Difference
| Type Number | Main Difference | Support Tags |
| CustomerNo-X | Most of the multi-antenna modules are customized according to the customer requirement, so the model is defined as CustomerNo-X | Mifare One S50,S70, FM11RF08 and compatible cards |
