| Type Number | Main Difference |
| RW208J-01 | USB Keyboard Emulation |
| ...... | USB Keyboard Emulation |
| RW208J-18 | USB Keyboard Emulation |
>>Features
- Will be replaced by RW210Jx
- USB keyboard emulation reader
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standards of ISO14443 TYPE A/Mifare
- The reader has the function of USB Human Interface Device keyboard emulation.The reader reads the Tag UID automatically,and then pastes it as a string at the cursor position into the host applications,like word,excel,notepad,brower,etc.
- Dimension:117mm*80mm*29mm
- Communication interface: USB
- Embeded with watchdog
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Output Data Difination
Please reference the user manual |
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:40~60mm(Testing base on standard S50)
- Power Supply:DC5V
- Current:Standard modules:5V/100mA
- Temperature range:-10℃～+70℃
- Demision:117mm*80mm*29mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| RW208J-XX | XX value=01-18 | Mifare S50,S70,FM11RF08,FM1204,FM1208, DesfireEV1 D21,D41,D81,Ultralight,Ntag203,213, 215,216 and compatible cards.But to the 7 bytes tag,the reader just output part of the CSN. |
