| Type Number | Main Difference |
| M209EEA | RS232 ISO14443A/B/ISO15693/ISO7816/Felica |
| M209EET | TTL232 ISO14443A/B/ISO15693/ISO7816/Felica |
| M209EEH | USB(HID) ISO14443A/B/ISO15693/ISO7816/Felica |
| M209EEAxSAM | RS232 +1-2SAM base ISO14443A/B/ISO15693/ISO7816/Felica |
| M209EETxSAM | TTL232 +1-2SAM base ISO14443A/B/ISO15693/ISO7816/Felica |
| M209EEHxSAM | USB(HID) +1-2SAM base ISO14443A/B/ISO15693/ISO7816/Felica |
| M209EHA | RS232 ISO15693 |
| M209EHT | TTL232 ISO15693 |
| M209EHH | USB(HID) ISO15693 |
>>Features
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standards of ISO14443 TYPE A/TYPE B/ISO15693/Filica/Mifare/ISO7816
- The module has the function of detecting whether the M1 card is a cloned card (Only for UID,not for the block data)
- Support 2 pcs PSAM base or 1 pc DIP8 base or 1 pc SOP8 ESAM
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Dimension include antenna:87X55X15mm
- Communication interface:UART/RS232/USB(HID)
- Souce code samples for C51,Android,Windows,Linux
- Embeded with watchdog
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Optional antennas(None)
| Type Number | Dimension | Operation Distance |
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:40~60mm(Testing base on standard S50)
- Power Supply:DC5V
- Communication interface:RS232/UART/USB(HID)
- Current: 5V/100mA
- Temperature range:-10℃～+70℃
- Demision:87X55X15mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| M209EEA | RS232 | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M209EET | UART | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M209EEH | USB(HID) | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M209EEAxSAM | RS232 + x=1-2 pcs SAM base | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M209EETxSAM | UART + x=1-2 pcs SAM base | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M209EEHxSAM | USB(HID) + x=1-2 pcs SAM base | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL CPU card, SRI512. SRI4K, typeB T=CL CPU card, I Code2, Tagit,Felica(Read UID only) and compatible cards |
| M209EHA | RS232 | ISO15693 NXP I code 2, TI HF tagit and compatible cards |
| M209EHT | UART | ISO15693 NXP I code 2, TI HF tagit and compatible cards |
| M209EHH | USB(HID) | ISO15693 NXP I code 2, TI HF tagit and compatible cards |
