| Type Number | Main Difference |
| RW208AA | RS232+ISO14443A |
| RW208AC | USB Virtual COM(CP2102)+ISO14443A |
| RW208AH | USB(HID)+ISO14443A |
| RW208DA | RS232+ISO14443A |
| RW208DB | RS485+ISO14443A |
| RW208DC | USB Virtual COM(CP2102)+ISO14443A |
| RW208DH | USB(HID)+ISO14443A |
| RW208HA | RS232+ISO15693 |
| RW208HC | USB Virtual COM(CP2102)+ISO15693 |
| RW208HH | USB(HID)+ISO15693 |
| RW208EA | RS232+ ISO14443A+ISO14443B+ISO15693+ISO7816 |
| RW208EC | USB Virtual COM(CP2102)+ ISO14443A+ISO14443B+ISO15693+ISO7816 |
| RW208EH | USB(HID)+ ISO14443A+ISO14443B+ISO15693+ISO7816 |
>>Features
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standards of ISO14443 TYPE A/TYPE B/ISO15693/Filica/Mifare/ISO7816
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Dimension:117mm*80mm*29mm
- Communication interface: RS232/RS485/USB
- Embeded with watchdog
- Souce code samples for Android,Java,Javascript,VC,VB,C++ Builder,DELPHI,Power Builder,C#,CVI,etc
- PC DEMO for users
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:40~60mm(Testing base on standard S50)
- Power Supply:DC5V
- Current:Standard modules:5V/100mA
- Temperature range:-10℃～+70℃
- Demision:117mm*80mm*29mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| RW208AA | RS232+ISO14443A | Mifare S50,S70,FM11RF08,FM1204,FM1208 and compatible cards |
| RW208AC | USB Virtual COM(CP2102)+ISO14443A | Mifare S50,S70,FM11RF08,FM1204,FM1208 and compatible cards |
| RW208AH | USB(HID)+ISO14443A | Mifare S50,S70,FM11RF08,FM1204,FM1208 and compatible cards |
| RW208DA | RS232+ISO14443A | Mifare S50,S70,FM11RF08,FM1208,Ultralight, NTAG203, NTAG213 NTAG215,NTAG216 and compatible cards |
| RW208DB | RS485+ISO14443A | Mifare S50,S70,FM11RF08,FM1208,Ultralight, NTAG203,NTAG213 NTAG215,NTAG216 and compatible cards |
| RW208DC | USB Virtual COM(CP2102)+ISO14443A | Mifare S50,S70,FM11RF08,FM1208,Ultralight, NTAG203, NTAG213 NTAG215,NTAG216 and compatible cards |
| RW208DH | USB(HID)+ISO14443A | Mifare S50,S70,FM11RF08,FM1208,Ultralight, NTAG203, NTAG213 NTAG215,NTAG216 and compatible cards |
| RW208HA | RS232+ISO15693 | ISO15693:ICode2,Tagit |
| RW208HC | USB Virtual COM(CP2102)+ISO15693 | ISO15693:ICode2,Tagit |
| RW208HH | USB(HID)+ISO15693 | ISO15693:ICode2,Tagit |
| RW208EA | RS232+ ISO14443A+ISO14443B+ISO15693+ISO7816 | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL的CPU卡 SRI512.SRI4K,typeB T=CL的CPU卡 I Code2,Tagit,Felica(只读UID), 二代证(只读UID),SAM9600,SAM38400及其兼容卡片 |
| RW208EC | USB Virtual COM(CP2102)+ ISO14443A+ISO14443B+ISO15693+ISO7816 | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL的CPU卡 SRI512.SRI4K,typeB T=CL的CPU卡 I Code2,Tagit,Felica(只读UID), 二代证(只读UID),SAM9600,SAM38400 and compatible cards |
| RW208EH | USB(HID)+ ISO14443A+ISO14443B+ISO15693+ISO7816 | Mifare One S50,S70, FM11RF08, Ultralight,Ntag203, Ntag 213,215,216,FM1208,Desfire, typeA T=CL的CPU卡 SRI512.SRI4K,typeB T=CL的CPU卡 I Code2,Tagit,Felica(只读UID), 二代证(只读UID),SAM9600,SAM38400 and compatible cards |
