| Type Number | Main Difference |
| M133CA | RS232 |
| M133CT | TTL232 |
>>Features
- Frequency: 13.56MHz
- Embeded NXP transceive IC as RF base sation
- Compliant with the standard of ISO14443 TYPE A/Mifare
- Completed operation command set,and user needn't to care for the complex control ,can implement all the operation for the IC cards.
- Integrated with antenna
- Dimension include antenna:63X35mm
- Communication interface:UART/RS232
- Souce code samples for C51,Android,Windows,Linux
- Embeded with watchdog
- Software can be customized according to the customer requirements
- Application for the fields of transport, access door control, smart meters, login in or login out checker, industrial,etc
>>Optional antennas(None)
| Type Number | Dimension | Operation Distance |
| T182 | 32.5X17.5mm | 20~30mm |
| T101 | 65X59mm | 50~70mm |
| T102 | 41X42mm | 30~40mm |
| T105 | 128X142mm | 80~100mm |
>>Electrical Characteristics
- Frequency: 13.56MHz
- Operation distance:40~60mm(Testing base on standard S50)
- Power Supply:DC3.3V/DC5V
- Communication interface:RS232/UART
- Current:High Power Modules:5V/100mA
- Temperature range:-10℃～+70℃
- Demision:63X35mm
- Pin to pin distance:2.54mm
>>Main Difference
| Type Number | Main Difference | Support Tags |
| M133CA | RS232 | Mifare S50,S70,FM11RF08,Ultraligh,Ntag FM1208, Desfire,T=CL TYPE A CPU card and compatible cards |
| M133CT | UART | Mifare S50,S70,FM11RF08, Ultraligh,Ntag FM1208, Desfire,T=CL TYPE A CPU card and compatible cards |
